MTB-70 Industrial Tubular Series
Ø70 mm Industrial LED Tri-Proof Tubular Light
A configurable industrial tubular luminaire for demanding environments, available in 600–1500 mm lengths and 20–70 W outputs, with flexible driver, control, wiring and emergency options.
Configuration, datasheet and quotation support within 1 business hour.
Product Overview
Balanced Diameter. Built for Industrial Projects.
The MANI MTB-70 is a robust LED tubular luminaire developed for industrial, commercial and infrastructure projects requiring dependable protection, uniform illumination and flexible configuration.
Its Ø70 mm profile provides greater internal capacity for high-output drivers, through-wiring, emergency modules and intelligent controls while maintaining a clean tubular form.
600 / 900 / 1200 / 1500 mm standard lengths
Protection against dust, moisture and impact
120 lm/W standard configuration
ON/OFF, DALI, 0–10V, TRIAC and sensor options
Surface-mounted, suspended and linkable options
CE and RoHS documentation available
Factory & Project Support
Built around your specificationProduct options matched to project requirements
Driver, control, wiring and installation guidance
Datasheets, test reports and compliance files
Production monitoring and final inspection
01 / BALANCED DESIGN
Balanced Diameter. Broader Industrial Capability.
With its Ø70 mm tubular profile, the MTB-70 provides a robust, well-balanced lighting solution for general industrial, commercial and infrastructure projects.
Reliable lighting for industrial facilities, production areas and logistics centres.
Suitable for car parks, metro stations, tunnels, service corridors and utility rooms.
Built for food processing areas, hygiene-sensitive sites and livestock facilities.
02 / PROTECTION & DURABILITY
IP67-IP69K
IK10
Built to withstand the most aggressive industrial conditions. The MTB-70 integrates an innovative triple-seal barrier with a central-screw fastening mechanism, guaranteeing even compression and enduring hermetic integrity against high dust, corrosive moisture, and high-pressure washdowns. Reinforced with UV- resistant polycarbonate and marine-grade stainless steel, it delivers total project peace of mind.
Ingress ratings, material grades and accessories are configuration-dependent. Confirm exact project specifications when requesting documentation or a quote.
03 / LIGHTING PERFORMANCE
Efficient, Uniform
Industrial Illumination
An integrated internal PC optical cover controls light diffusion and delivers consistent, low-glare illumination (UGR < 21) across workspaces, aisles and circulation areas. Standard efficacy is 120 lm/W, with selected high-efficiency versions available up to 150 lm/W.
Actual performance varies by CCT, CRI, diffuser, driver and emergency configuration.
04 / DRIVER & CONTROL
Stable Power.
Flexible Control.
Our Ø70 mm LED tri-proof tubular light is powered by premium Tridonic isolated drivers, providing exceptional electrical safety and rock-solid performance for demanding industrial projects. Select the control configuration needed for your application—from straightforward ON/OFF operation to project-specific dimming and intelligent control options.
Voltage and control options are configuration-dependent. Confirm final compatibility when requesting a quotation.
05 / INSTALLATION & CONNECTIVITY
Faster Wiring.
Cleaner Projects.
Choose the connection method that best fits your installation. The MTB-70 supports factory pre-wired, quick-connect and plug-and-play configurations to reduce on-site wiring time and simplify individual or continuous lighting layouts.
Connector type, cable length and wiring configuration can be selected according to project requirements.
06 / SMART CONTROL & EMERGENCY
Smarter Control.
Safer Operation.
Configure the MTB-70 for more responsive, energy-conscious lighting. Optional microwave sensing provides occupancy-based control, while emergency versions help maintain essential illumination when normal power is interrupted.
Sensor, emergency and control functions are optional and configuration-dependent. Confirm final compatibility when requesting a quotation.
Proven Across
Industrial Applications
From production facilities and transport infrastructure to food processing and agricultural environments, the MTB-70 can be configured around application conditions, installation methods, control requirements and project specifications.
FACTORY SPECIFICATIONS & ENGINEERING DATA
Clear Data.
Flexible Configuration.
Factory photometric, electrical and material specifications for the Ø70 mm MTB-70 tubular series. Built with industrial-grade isolated drivers and reinforced mechanical components for demanding tenders and harsh industrial environments.
OEM / ODM SYSTEM CUSTOMIZATION
Control & Functional Configurations
Factory-integrated control options matched to tender and site requirements.
STANDARD PRODUCTION CATALOGUE MTB-70 Standard Model Matrix 4 factory models
| Model No. | Dimension | System Power | Input Voltage | Nominal Luminous Flux | Efficacy |
|---|---|---|---|---|---|
| MTB-706020 | L600 × Ø70 mm | 20 W | AC 220–240 V / 100–277 V | 2,400 lm | 120 lm/W |
| MTB-709030 | L900 × Ø70 mm | 30 W | AC 220–240 V / 100–277 V | 3,600 lm | 120 lm/W |
| MTB-701240 | L1200 × Ø70 mm | 40 W | AC 220–240 V / 100–277 V | 4,800 lm | 120 lm/W |
| MTB-701550 | L1500 × Ø70 mm | 50 W | AC 220–240 V / 100–277 V | 6,000 lm | 120 lm/W |
Related Products
Explore alternative diameters, materials and specialist tubular lighting solutions for different project requirements.
Swipe to explore
Ø45 mm LED Tri-Proof Tubular Light
A compact tubular luminaire delivering balanced performance for space-restricted applications.
View product
Ø100 mm LED Tri-Proof Tubular Light
A larger-diameter solution designed for higher-output industrial lighting applications.
View product
Ø75 mm Borosilicate Glass LED Tri-Proof Tubular Light
Borosilicate glass construction for specialist environments requiring durable material performance.
View product
Signal & Safety LED Tri-Proof Tubular Lights
Illuminated identification, warning and directional solutions for industrial facilities.
View product
Questions,
answered.
Key information about performance, installation and configuration options for the Ø70mm tubular light platform.
The standard configuration is rated at 120 lm/W, while selected high-efficiency configurations can achieve up to 150 lm/W. Actual output depends on wattage, CCT, CRI, diffuser, driver and emergency configuration.
The luminaire is rated IP67, providing protection against dust and temporary water immersion under specified test conditions. It is suitable for wet and frequently cleaned environments, but is not intended for permanent underwater operation.
Yes. Its sealed construction, UV-resistant polycarbonate housing and optional stainless steel components make it suitable for humid and dusty agricultural environments. Cleaning agents and site conditions should be confirmed when selecting the final material configuration.
Yes. Quick-connect, through-wired and plug-and-play configurations are available for continuous lighting layouts. The permitted number of luminaires depends on total electrical load, cable specification, driver selection and local installation requirements.
Available control options include ON/OFF, DALI, TRIAC and 0–10V. Microwave motion sensors and project-specific control configurations can also be provided, depending on the selected driver and wiring arrangement.
Yes. A 3-hour emergency version is available for selected configurations. Emergency output, battery type, test function and applicable certification should be confirmed when requesting a quotation.
