SWAP SERIES · COMMERCIAL TRI-PROOF T8 TUBULAR LIGHT
Replace the Tube.
Keep the Luminaire.
Swap places a replaceable T8 LED tube inside a durable protective housing, combining straightforward maintenance and flexible lamp selection with reliable IP65 ingress protection and IK10 impact resistance. Available in Ø70 mm and Ø100 mm profiles, multiple lengths, and surface or suspended mounting, it is designed for commercial and public environments where lighting needs to remain serviceable over time.
Specify the profile diameter, fixture length, T8 lamp, wiring method, mounting type and SS304L or SS316L stainless-steel end caps. Technical drawings, certification documents and project data are available on request.
PRODUCT & MANUFACTURING CAPABILITIES
Replaceable T8 lighting.
Protected for long-term use.
Swap combines a replaceable T8 LED tube with a durable protective housing, making lamp replacement and future maintenance straightforward without requiring the complete luminaire to be replaced. Multiple diameters, lengths, wiring configurations and mounting options allow it to be adapted to commercial and public environments where flexibility, protection and long-term serviceability are essential.
Replaceable T8 Design
The internal T8 LED tube can be removed and replaced independently, simplifying routine maintenance and extending the useful service life of the complete luminaire.
Flexible Lamp Selection
The replaceable lamp concept allows the T8 LED tube to be selected according to project-specific output, color temperature and performance requirements.
Protective Tubular Housing
The UV-resistant polycarbonate housing protects the internal T8 tube from moisture, dust and physical impact while creating a clean, unified appearance.
Flexible Length & Mounting
Available in 600 mm, 900 mm, 1200 mm and 1500 mm formats, with surface-mounted or suspended installation to suit different spaces and layouts.
Configurable T8 Wiring
The luminaire can be configured for compatible single-ended or double-ended T8 LED tube power input according to the selected lamp and project wiring requirements.
Commercial-Grade Protection
IP65 ingress protection, IK10 impact resistance, UV-resistant PC housing, stainless-steel end caps and a 960°C glow-wire rating support reliable use in demanding commercial and public environments.
Project Configuration
Profile diameter, fixture length, compatible T8 lamp specification, single- or double-ended wiring, mounting method and SS304L or SS316L end-cap material coordinated to project requirements.
Lamp & Housing Verification
Pre-production samples allow T8 lamp compatibility, replacement access, lamp-holder fit, wiring configuration, mounting details, sealing and finished appearance to be reviewed before production.
Engineering & Installation Data
Configuration drawings, T8 compatibility information, wiring diagrams, installation details, electrical data and certification documentation prepared for project coordination and approval.
Electrical & Protection Testing
Lamp-holder contact, electrical operation, wiring accuracy, sealing integrity, component fit and finished appearance inspected before delivery.
01 / PROTECTIVE TUBULAR HOUSING
Give replaceable T8 lighting the protection commercial spaces demand.
Swap encloses a replaceable T8 LED tube within a durable, UV-resistant polycarbonate housing. It combines the familiarity and flexibility of the T8 lamp format with the environmental, mechanical and safety protection required in demanding commercial and public environments.
IP65 protection helps shield the internal T8 tube and electrical components from dust and water ingress.
The IK10-rated polycarbonate housing protects the lamp against accidental impact in high-traffic and service areas.
UV-resistant PC, SS304L or SS316L stainless-steel end caps and a 960°C glow-wire rating support reliable long-term use.
02 / LONG-TERM SERVICEABILITY
Replace the T8 tube—not the complete luminaire.
When the lamp reaches the end of its service life or project requirements change, the internal T8 LED tube can be replaced independently. The protective housing, mounting components and main luminaire structure remain in use, simplifying maintenance while helping reduce unnecessary full-fixture replacement.
03 / PROJECT-READY CONFIGURATION
Configure one protected T8 system around the project.
Swap is available in multiple diameters, lengths, wiring arrangements and mounting formats, allowing the luminaire to coordinate with different T8 lamp specifications, ceiling conditions and electrical requirements across new-build and replacement projects.
Choose Ø70 mm or Ø100 mm profiles in 600 mm, 900 mm, 1200 mm or 1500 mm formats to match compatible T8 tube sizes.
Specify single-ended or double-ended power input according to the selected T8 LED tube and project wiring requirements.
Configure the luminaire for surface-mounted or suspended installation, with SS304L or SS316L stainless-steel end caps.
TECHNICAL SPECIFICATIONS
Clear Data.
Serviceable T8 Platform.
Factory mechanical, electrical, and compatibility specifications for the Swap Commercial Tri-Proof T8 Tubular Luminaire. Available across Ø70 mm and Ø100 mm profiles with UV-resistant PC housings and SS304L/SS316L stainless steel end caps for durable, serviceable project installations.
OEM / ODM SYSTEM CUSTOMIZATION
Mounting, Wiring & Customization Configurations
Factory-engineered mounting, wiring, and lamp arrangements matched to project requirements.
SLIM COMMERCIAL SERIES Ø70 mm Standard Model Matrix (SWAP-70) 4 standard formats
| Model No. | Dimension | Compatible Lamp | Input Voltage | Wiring Method | Mounting Type |
|---|---|---|---|---|---|
| SWAP-70-060 | L600 × Ø70 mm | 1 × T8 LED Tube (0.6 m / ~9 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
| SWAP-70-090 | L900 × Ø70 mm | 1 × T8 LED Tube (0.9 m / ~14 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
| SWAP-70-120 | L1200 × Ø70 mm | 1 × T8 LED Tube (1.2 m / ~18 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
| SWAP-70-150 | L1500 × Ø70 mm | 1 × T8 LED Tube (1.5 m / ~24 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
HEAVY-DUTY ROBUST SERIES Ø100 mm Standard Model Matrix (SWAP-100) 4 standard formats
| Model No. | Dimension | Compatible Lamp | Input Voltage | Wiring Method | Mounting Type |
|---|---|---|---|---|---|
| SWAP-100-060 | L600 × Ø100 mm | 2 × T8 LED Tube (0.6 m / ~9 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
| SWAP-100-090 | L900 × Ø100 mm | 2 × T8 LED Tube (0.9 m / ~14 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
| SWAP-100-120 | L1200 × Ø100 mm | 2 × T8 LED Tube (1.2 m / ~18 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
| SWAP-100-150 | L1500 × Ø100 mm | 2 × T8 LED Tube (1.5 m / ~24 W) | AC 220–240 V / 100–277 V | Single / Double-Ended | Surface / Suspended |
Proven Across
Diverse Facilities
From multi-story parking structures, transit corridors, and maintenance tunnels to commercial logistics hubs, public utilities, and manufacturing facilities, Swap delivers serviceable T8 illumination backed by robust IP65 ingress protection and IK10 impact durability.
